AMETEK Pneumatic Hand Pump T-960 (0-30 PSI, 2 Bar)
السعر العادي
2,857.14 SR
لم نتمكن من تحميل توفر الاستلام
Use this text to encourage communication or promote sharing on social networks.
The AMETEK T-960 Pneumatic Hand Pump is designed for generating pressure and vacuum with precision and ease. It is particularly useful for calibrating pressure instruments and testing various devices in industrial applications.
Features
- Pressure Range: The T-960 can generate pressures from 0 to 30 PSI (0 to 2 Bar).
- Medium: Designed to work with air.
-
Pressure Connections:
- Reference Port: 3/8" BSP Female (with adapters available for 1/4" NPT Female and 1/4" BSP Female).
- Device Under Test Port: 1/4" NPT Female and 1/4" BSP Female.
- Fine Adjustment: Equipped with a fine adjust valve for precise control.
- Overpressure Protection: Features stroke adjustment to prevent overpressure.
- Material Construction: Made from anodized aluminum, brass, ABS, and stainless steel.
- Dimensions: The pump measures 216 mm (L) x 121 mm (W) x 62 mm (D).
- Standard Supply: Comes with a 1.0-meter hose.
Specifications
| Specification | Details |
|---|---|
| Model No | T-960 |
| Pressure Range | 0 to 30 PSI (0 to 2 Bar) |
| Medium | Air |
| Reference Port | 3/8" BSP Female |
| Device Under Test Port | 1/4" NPT Female and 1/4" BSP Female |
| Fine Adjustment | Yes |
| Overpressure Protection | Stroke adjustment |
| Material | Anodized aluminum, Brass, ABS, Stainless Steel |
| Dimensions | 216 x 121 x 62 mm |
| Standard Supply | 1.0 meter hose |
