Three models to choose from, with or without True RMS and AC or AC/DC Current functions. Choose True RMS model for accurate readings of non-sinusoidal waveforms, model with DC Current function for automotive applications, or model with Type K function when applications require Temperature measurements. The MA440 Series meters are fully loaded with multimeter functions and built-in non-contact voltage (NCV) detector to meet your application needs!
Features
• 1.2" (30mm) jaw size fit conductors up to 500MCM
• Built-in Non-Contact Voltage (NCV) detector
• MultiMeter functions include Resistance,
Capacitance and Frequency
• Relative Mode for Capacitance
• Data Hold freezes reading on display
• Auto Power Off with disable and Low Battery indication
• Large backlit LCD display
• Complete with test leads, three AAA batteries, and
pouch; MA443 and MA445 also includes a general
purpose Type K Temperature probe*
Specifications
| Specification | Value |
|---|---|
| AC Current | 400.0 A |
| AC Current Basic Accuracy | ±2.0% |
| AC Current Max Resolution | 1 mA |
| AC Voltage | 600 V |
| AC Voltage Basic Accuracy | ±1.2% |
| AC Voltage Max Resolution | 1 mV |
| Capacitance | 100 µF |
| Capacitance Max Resolution | 0.01 nF |
| Continuity | Yes |
| DC Voltage | 600 V |
| DC Voltage Basic Accuracy | ±0.8% |
| DC Voltage Max Resolution | 0.1 mV |
| Diode Test | Yes |
| Frequency | 1 MHz |
| Frequency Max Resolution | 0.01 Hz |
| Jaw Size | 1.2" (30 mm), conductors up to 500 MCM |
| Non-Contact Voltage (NCV) Detector | 100 to 600 VAC |
| Resistance | 40 MΩ |
| Resistance Max Resolution | 0.1 Ω |
| True RMS | Yes |
| Certifications | CE, ETL |
| Dimensions | 9 × 3 × 1.6" (228 × 77 × 41 mm) |
| Power | 3 × AAA (1.5 V) batteries |
| Safety Category | CAT III - 600 V |
| Warranty | 2 years |
| Weight | 9.3 oz (265 g) |
