Fluke 323 True RMS Clamp Meter
Regular price
750.00 SR
Couldn't load pickup availability
Use this text to encourage communication or promote sharing on social networks.
The Fluke 323 clamp meter is a good basic troubleshooting tool for commercial and residential electricians. It includes True RMS measurements, optimized ergonomics, and large display for efficient troubleshooting. It's designed to perform in the toughest environments and provide noise-free, reliable results, so you can trust it to help you confidently diagnose problems almost anywhere. Use it to verify the presence of load current, AC voltage, and continuity of circuits, switches, fuses and contacts. Its slim, compact size and rugged design make it well suited for measuring current up to 400 A in tight cable compartments.
Features
- Rugged, reliable basic True-RMS clamp meter for measuring current up to 400 A
- Measures AC current to 400 A
- Measures AC voltage and DC voltage to 600 V
- Provides True RMS AC voltage and current for accurate measurements on non-linear signals
- Measures resistance to 4 kΩ with continuity detection
Specifications
| Specification | Value |
|---|---|
| AC Current Range | 400.0 A |
| AC Current Accuracy | 2% ± 5 digits (45 Hz to 65 Hz) |
| 2.5% ± 5 digits (65 Hz to 400 Hz) | |
| DC Current Range | - |
| DC Current Accuracy | - |
| AC Voltage Range | 600.0 V |
| AC Voltage Accuracy | 1.5% ± 5 digits |
| DC Voltage Range | 600.0 V |
| DC Voltage Accuracy | 1.0% ± 5 digits |
| Resistance Range | 400.0 Ω / 4000 Ω |
| Resistance Accuracy | 1.0% ± 5 digits |
| Continuity | ≤ 70 Ω |
| Capacitance | - |
| Frequency | - |
| AC Response | True-RMS |
| Backlight | - |
| Data Hold | Yes |
| Contact Temperature | - |
| Min/Max | - |
| Size (H x W x D) | 207 x 75 x 34 mm |
| Max Wire Diameter | 30 mm (600 MCM) |
| Weight | 265 g |
| Category Rating | CAT III 600 V; CAT IV 300 V |
| Warranty | Two years |
