Fluke 378FC Clamp Meter

Out of stock
SKU: 378FC
Regular price 3,500.00 SR

Use this text to encourage communication or promote sharing on social networks.

You can also add links


The Fluke 378FC is a Non-Contact Voltage True-RMS AC/DC Clamp Meter equipped with advanced FieldSense™ technology, allowing for safe and efficient measurements without direct contact with live conductors. This meter is ideal for electrical professionals who require accurate voltage and current readings in various applications.

Features
  • FieldSense Technology: Enables voltage and current measurements through the clamp jaw without touching live wires, enhancing safety and efficiency.
  • Power Quality Indicator: Automatically detects power quality issues related to current, voltage, and power factor, helping to identify upstream supply problems or downstream equipment issues.
  • Three-Phase Measurements: Simplifies three-phase voltage and current tests, providing complete phase-to-ground and phase-to-phase values in just three steps.
  • iFlex Probe: Includes an iFlex flexible current probe that allows for measuring AC current up to 2500 A, making it easier to access crowded wiring cabinets and large conductors.
  • User-Friendly Display: Features a dual readout display that shows voltage and current measurements simultaneously, with visual continuity indicators for easy detection in noisy environments.
Specifications
Specification Details
AC Current (Jaw) Range: 999.9 A, Accuracy: 2% ±5 digits
AC Current (iFlex Probe) Range: 2500 A, Accuracy: 3% ±5 digits
DC Current Range: 999.9 A, Accuracy: 2% ±5 digits
AC Voltage (FieldSense) Range: 1000 V, Accuracy: 3% ±5 digits
AC Voltage (Test Leads) Range: 600.0 V / 1000 V, Accuracy: 1% ±5 digits
Resistance Range: 60.00 kΩ / 6000 Ω / 600.0 Ω, Accuracy: 1% ±5 digits
Capacitance Range: 1000 μF, Accuracy: 1% ±4 digits
Operating Temperature -10 °C to 50 °C
Dimensions 274 mm x 86 mm x 47 mm
Weight 463 g (with batteries)
