Fluke 378FC Clamp Meter
Regular price
3,500.00 SR
Couldn't load pickup availability
Use this text to encourage communication or promote sharing on social networks.
The Fluke 378FC is a Non-Contact Voltage True-RMS AC/DC Clamp Meter equipped with advanced FieldSense™ technology, allowing for safe and efficient measurements without direct contact with live conductors. This meter is ideal for electrical professionals who require accurate voltage and current readings in various applications.
Features
- FieldSense Technology: Enables voltage and current measurements through the clamp jaw without touching live wires, enhancing safety and efficiency.
- Power Quality Indicator: Automatically detects power quality issues related to current, voltage, and power factor, helping to identify upstream supply problems or downstream equipment issues.
- Three-Phase Measurements: Simplifies three-phase voltage and current tests, providing complete phase-to-ground and phase-to-phase values in just three steps.
- iFlex Probe: Includes an iFlex flexible current probe that allows for measuring AC current up to 2500 A, making it easier to access crowded wiring cabinets and large conductors.
- User-Friendly Display: Features a dual readout display that shows voltage and current measurements simultaneously, with visual continuity indicators for easy detection in noisy environments.
Specifications
Specification | Details |
---|---|
AC Current (Jaw) | Range: 999.9 A, Accuracy: 2% ±5 digits |
AC Current (iFlex Probe) | Range: 2500 A, Accuracy: 3% ±5 digits |
DC Current | Range: 999.9 A, Accuracy: 2% ±5 digits |
AC Voltage (FieldSense) | Range: 1000 V, Accuracy: 3% ±5 digits |
AC Voltage (Test Leads) | Range: 600.0 V / 1000 V, Accuracy: 1% ±5 digits |
Resistance | Range: 60.00 kΩ / 6000 Ω / 600.0 Ω, Accuracy: 1% ±5 digits |
Capacitance | Range: 1000 μF, Accuracy: 1% ±4 digits |
Operating Temperature | -10 °C to 50 °C |
Dimensions | 274 mm x 86 mm x 47 mm |
Weight | 463 g (with batteries) |
