Fluke 771 Milliamp Process Clamp
Regular price
2,700.00 SR
Couldn't load pickup availability
Use this text to encourage communication or promote sharing on social networks.
The Fluke 771 Milliamp Process Clamp Meter is designed for measuring 4 to 20 mA signals without breaking the loop, making it ideal for troubleshooting and maintaining process and automation equipment. This clamp meter is particularly useful for professionals who need to measure low-level DC current without taking systems offline.
Features
- Non-Intrusive Measurement: Measures 4-20 mA signals without interrupting the loop, allowing for continuous operation during testing.
- High Accuracy: Offers best-in-class accuracy of 0.2%, ensuring reliable measurements.
- Detachable Clamp: The detachable clamp allows for measurements in tight spaces while the meter can be positioned for easy viewing.
- Dual Backlit Display: Displays both the mA measurement and the percentage of the 4 to 20 mA span, facilitating quick analysis.
- LED Spotlight: Illuminates hard-to-see wires in dark enclosures, enhancing usability in various environments.
Specifications
Specification | Details |
---|---|
Diameter of Measurable Conductor | 0.177 in (4.5 mm) max |
Operating Temperature | -10 to 50 °C |
Storage Temperature | -25 to 60 °C |
Operating Humidity | < 90% @ < 30 °C, < 75% @ 30 to 55 °C |
Operating Altitude | 0 to 2000 m |
IP Rating | IP 40 |
Size | 59 x 38 x 212 mm |
Weight | 260 g (9.1 oz) |
Power Supply | (2) AA 1.5 V Alkaline, 40 hours typical |
Warranty | Three years for electronics, one year for cable and clamp assembly |
